SWF Classic Art Deco
Replicate traditional Art Deco style Cockspur handle which operates a concealed multipoint rail system. Comes with a Key-Locking facility for added security and matching screw cover caps.
Stock finishes and full RAL availability.
There are three colour options available for our Royale Windows at reduced cost and reduced lead time when compared to other RAL colours. White being the cheapest and quickest option.
Our Textured Colour Range is a cost effective and unique range of metallic and textured paint finishes. They are ideal for both modern architecture and restoration projects.
Our Aluminium Windows are available in any single or dual special RAL colour paint finish. There are over two hundred different RAL colours available.
Double and triple glazing options available with enhanced thermal, acoustic and solar performance.
Our high security handle options drive modern high security multipoint shootbolt locking and are available in a range of different colours.
Replicate traditional Art Deco style Cockspur handle which operates a concealed multipoint rail system. Comes with a Key-Locking facility for added security and matching screw cover caps.
These handles have a straigher inline design. As a result they do not protrude as far into the glass sight-line. Suitable for use on top hung windows.
Period Monkey Tail design replicating traditional iron mongery of the early 20th century. Key-Locking facility for added security and finished with matching screw cover caps.
Traditional Art Deco style handles operating multipoint locking. For added security these handles come with a Key-Locking facility and the handle fixings are concealed within the glazing beads.
Cockspur handles have no internal locking mechanism and instead rely on the spur, which when closed secures the window at the handle. These handles have a key locking facility and are available in a range of colours.
They only provides a single locking point and therefore several handles may be required to secure larger windows. You can specify different handles on the top hung openers and side hung openers.
The window is secured at the handle via pressure exerted on a wedge plate on the frame. These handles come with a Key-Locking facility for added security and are finished with colour matched screws.
A straighter inline design, these handles do not protrude as far into the glass sight-line. The angle of the arm of these handles makes them more suitable for use on top hung windows.
The window is secured at the handle via pressure exerted on a wedge plate on the frame. These handles come with a Key-Locking facility for added security and are finished with colour matched screws.
These handles come with a Key-Locking facility for added security and are finished with colour matched screws. There is a range of stricking colour finishes to choose from.
An authentic looking window from the outside, in keeping with modern interiors (with anti-ligature aspects).
Designed to look like period ironmongery of the early 20th century.
Monkey Tail Peg Stay often used on residential properties but equally at home on Commercial.
Industry standard, egress and restrictor hinge options for different opening requirements.
Friction hinges are the industry standard window hinge, it remains open by means of friction in the hinge. The clever design of the hinge allows you to keep your window open in any given position without the need for a old fashioned Peg & Stay.
Egress Easy Clean hinges are fire escape hinges, which allow windows of over 350mm wide to comply to Part B (for fire safety) of the Building Regs. They can also slide across to enable cleaning of the outside glass, as with standard friction hinges.
Restrictor hinges are safty hinges that provide a restricted opening of between 7° - 16° depending on the size of the opening, allowing for ventilation, while protecting against accidental falling. You can release and fully open the window for cleaning.
Note: The exact opening angle depends on the size of your opening. Please ask for more details.
Optional heritage hinge styles for a more authentic traditional appearance.
Dummy butt hinges are an optional extra. They are designed to give the appearance of working butt hinges, without the cleaning and safety considerations, of working butt hinges. The rollers are concealed by the sliding sash, which overlaps and runs on the track like a monorail.
Dummy Parliament hinges are an optional extra. They are designed to give the appearance of traditional parliament hinges, projecting out from the frame, but without the safety considerations, of working Parliament hinges.
Our Profile related working butt hinges will give you a truly authentic look, when the window is open and closed. In a closed position the hinges interlock and act as sash jammers. Used in conjunction with a Peg & Stay (not recommended for upper floors).
Royale Putty-Line windows combine heritage styling with modern protection, including multipoint locking, secure hinges, key-locking handles, sash jammers and internally glazed sashes.
If you choose one of the high security locking handle options, the window benefits from a high security multipoint lock with mushroom cams, heavy duty keeps and shootbolts to the top and bottom of the sash.
Additional protection comes from security hinges, key locking handles, secure night vent positions, concealed handle fixings and internal glazing.
High security locking handle options operate a multipoint lock with bi-directional mushroom cams, heavy duty keeps and shootbolts to the top and bottom of the sash for excellent compression and smooth operation.
Windows are fitted with high-strength stainless steel friction stays or profile-related butt hinges. Friction hinges help secure the sash, while profile-related butt hinges include interlocking elements that help protect the hinge edge.
All handle options include key locking as standard, allowing the handle to be secured from the inside for added peace of mind and improved compliance with many insurance requirements.
Heritage windows include sash jammers, or vector excluders, which interlock when the window is closed to help secure the hinge edge without affecting normal opening and closing performance.
Additional keeper positions allow the window to be secured in a slightly open position, helping provide background ventilation while maintaining security.
Chelton handle fixings are concealed beneath the glazing bead, so the handles cannot be easily unscrewed to access the locking mechanism from the visible side.
Opening and dummy sashes are internally glazed for added protection, and laminated security glass can also be specified for enhanced resistance if higher performance is required.
Recommended sizes, performance data, profile dimensions and sightline details.
These statistics apply for 18mm double-glazed sealed units, 92% krypton gas filled, Pilkington Total+ and 8mm spacer. Glass centre pane U-value: 0.74. Stats to be confirmed by testing carried out by Wintech.
Please note: Sight-lines depend on whether you specify the traditional couplers only construction or the transoms and mullions construction (No Show Couplers / Couplers / Transoms & Mullions). The SW0052 / 0053 outerframe is used when the transoms and mullions construction is specified; this results in 32mm externally glazed fixed lites.
1 If trickle vents are required they are inserted into the 42mm head extension.
2 An optional 25mm projection cill can be added to protect the brick work under the doors.
Download specification sheets and full product brochures.
